S波段T/R双工SiP?椋1W/2W)

0.0/5 rating (0 votes)

Description

产品特点
●  细步进
●  低相噪
●  低杂散
●  体积小
●  气密性好
●  可靠性高

典范应用
●  航空
●  机载19

接收通道电性能参数(TA=+25℃,Vdd=+5V,Vee=-5V)

参数名称

单位

最小值

典范值

最大值

频率

MHz

-

S

-

噪声系数

dB

-

-

2

增益

dB

32

-

-

全频段增益变革

dB

-

±0.75

-

通道一致性

dB

-

±0.75

-

输出P-1

dBm

15

-

-

输入输出阻抗

Ω

-

50

-

输入/输出回波损耗

dB

-

-

-10

数控移相器

bit

-

6

-

数控衰减器

bit

-

4

-

滤波器带外抑制@发射频率

dB

70

-

-

+5V事情电流

mA

-

130

-

发射通道电性能参数(TA=+25℃,Vdd=+5V,Vee=-5V)

参数名称

单位

最小值

典范值

最大值

频率

MHz

-

S

-

增益

39

-

-

全频段增益变革

dB

-

±0.5

-

通道一致性

dB

-

±0.75

-

输出P-1(线性输出,含双工器)

dBm

30/33

-

-

输入输出阻抗

Ω

-

50

-

输入/输出回波损耗

dB

-

-

-10

数控移相器

bit

-

6

-

数控衰减器

bit

-

4

-

滤波器带外抑制@接收频率

dB

70

-

-

+5V事情电流

mA

-

770

-













Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
